Delivery Time : | within 30 days |
Payment Terms : | 30% TT as deposit,70% balanced before delivery |
Supply Ability : | 30 set per month |
Brand Name : | JS MACHINE |
Certification : | CE SGS ISO |
Model Number : | JS |
Price : | Negotiation |
Qingdao FEIFAN Packing Machinery FFA Series Packing Machinery
1. Reliable and stable system, low maintenance, programmable controller.
2. Video-display contains length of packing film, speed, output, temperature of packing etc.
3. Adopt PLC control system, reduce mechanical contact.
4. Frequency control, convenient and simple.
5. Bidirectional automatic tracking, color control patch by photoelectric detection
6. The main electrical elements adopt well-known international brands.
FFA450 Series | 450/99 | 450/120 | 450/150 | 450/180 |
Max Film Width (mm) | 450 | 450 | 450 | 450 |
Speed (Bag/ min) | 30-220 | 30-220 | 30-220 | 30-220 |
Packing Length (mm) | 70-450 | 70-450 | 90-450 | 100-450 |
Packing Width (mm) | 10-150 | 10-150 | 10-150 | 10-150 |
Packing Height (mm) | 5-45 | 5-65 | 5-85 | 5-120 |
Electric Power Voltage (v) | 220 | 220 | 220 | 220 |
Total Installed Power | 3.5 | 3.6 | 3.6 | 3.6 |
Weight (kg) | 1000 | 1000 | 1000 | 1000 |
Dimensions (L*W*H) (mm) | 5700*1050*1700 | 5700*1050*1700 | 5700*1050*1700 | 5700*1050*1700 |
Packing Material | Paper/PE, OPP/PE, OPP/AL/PE, POF etc |
FFA590 Series | 590/120 | 590/150 | 590/180 |
Max Film Width (mm) | 590 | 590 | 590 |
Speed (Bag/ min) | 30-200 | 30-200 | 30-200 |
Packing Length (mm) | 80-450 | 90-450 | 100-450 |
Packing Width (mm) | 10-200 | 10-200 | 10-200 |
Packing Height (mm) | 5-65 | 5-85 | 5-120 |
Electric Power Voltage (v) | 220 | 220 | 220 |
Total Installed Power | 4 | 4 | 4 |
Weight (kg) | 1200 | 1200 | 1200 |
Dimensions (L*W*H) (mm) | 5700*1250*1800 | 5700*1250*1800 | 5700*1250*1800 |
Packing Material | Paper/PE, OPP/PE, OPP/AL/PE, POF etc |
![]() |
